Katana Rocker 243/4x80, TRI

Katana Rocker 243/4x80, TRI

520068 | Black | Pair
Regular price €83,30 EUR
Sale price €83,30 EUR

SRP: 119,99 € | $135.99 | £109.99

POWERSLIDE Katana Rocker 80 / 243 frame - High-performance frame for freestyle inline skating. Trinity mounting, aluminum, rockerable, max. 4x80mm wheels

Packing Unit: 15

View full details

For superb performance with the benefits of the famous TRINITY mounting system, POWERSLIDE Katana Rocker 80 - 243 TRI is one of the absolute best freestyle inline skating frames out there. Perfect for freestyle inline skating where control, speed, and rapid acceleration are crucial, the frame is engineered around the 3-point TRINITY mounting system that brings your wheels close to your foot in order to give you unmatched stability, control, and power transfer. Thanks to the TRINITY mounting system the Katana Rocker frame is compatible with a wide range of boots including the POWERSLIDE Tau or HC Evo. TRINITY you can easily create the perfect freestyle setup or try a wide range of different types of frames - big wheel, urban, fitness, even off-road SUV. To make the frame lightweight improve responsiveness even further, the frame is made of high-grade aluminum. By simply turning the two center axles 180 degrees the Katana Rocker 80 is a versatile frame that allows you to choose the perfect rocker position to meet your individual needs. Experience the unmatched performance of the Katana Rocker 80 - 243 TRI for yourself.

Boot specs

Boot Mounting Standard TRINITY 3-point mounting
Adjustable Front to Back Yes
Adjustable Side to Side Yes

Frame/plate specs

Frame Mounting Standard TRINITY 3-point mounting
Frame Setup 4x80mm
Frame Material AL 6061 aircraft
Brake Option No brake available
Frame Axles Single axle, AL 7075, 8mm, Torx T25, L=35mm + rocker double axle, steel, 8mm, Torx T25, L=33mm
Frame Construction Double void
Frame Manufacturing Process Extruded and CNC machining
Frame Spacer Built in and CNC machined
Frame Wheel Base (Inch / MM) 9.6" / 243mm
Max. Wheel Size 80mm
Standing Height Front / Rear in MM 72,0mm / 83,0mm

General specs

Segments Urban  - Fitness  - Hockey
Components AL Single Axle, Torx 35mm/8mmSteel Rocker Double Axle, Torx 33mm/8mm
Extra Features Special rocker axle - all wheels have the same diameter
Included Accessories AL axles, AL spacers, mounting screws 4x14mm / 2x12mm, tool - Torx T25
Net weight (kg) 0.726
Gross weight (kg) 0.793
Packaging Size 12,5 x 8 x 36
Weight 0.793
VPE Gross weight (kg) 11,9
VPE Net weight (kg) 10,9
VPE Packaging 45 x 36 x 41
VPE Product QTY 15
Warranty 2 Years
Release Year 20
